Project Overview
Crossroads Solar is pleased to partner with Fountain County landowners on a proposed 200-megawatt (MW) solar photovoltaic generation facility. The project will be a source of clean, locally generated electric power, while diversifying farm income and providing significant environmental and economic benefits in the local community.
Rows of panels will track the sun
The project will feature rows of solar panels, surrounded by prairie grasses and pollinators compatible with grazing and beekeeping. The panels will track the sun throughout the day. Significant spacing between rows – typically about 16 to 20 feet – prevents shading of adjacent rows, allows for maintenance, and allows ample space for vegetation between rows.
Panels will be set back from homes, roads, and from the boundaries of properties that are not participating in the project.
The project will use a simple design that minimizes soil disturbance, with solar panels mounted on racks attached to steel posts that have been driven into the ground. Rows of panels will be arranged along a north-south axis, and the panels will rotate from east to west throughout the day to efficiently capture the sun’s energy.
The panels are designed to absorb light and include an anti-glare coating. These features, coupled with the sun-tracking motion, limit glare in the area around the facility. Of note, similar panels and facilities are frequently sited with Federal Aviation Administration approval adjacent to airports.
Buried wires connecting the rows of panels will lead first to inverters that convert direct current to alternating current, and then from inverters to a step-up transformer, where the voltage will be increased to transmission system levels for connection to the existing transmission substation located along Public Service Road, west of Veedersburg. The project substation and transformer will be located adjacent to the existing substation. Importantly, the location of the project is optimized to minimize the need for new transmission infrastructure, such as lines and towers.
Panel rows will be generously spaced
To minimize shadows on adjacent rows, to allow for maintenance, and to allow ample space for vegetation between rows, the centers of rows will be spaced about 16-20 feet apart, leaving wide gaps between, even when panels are flat at midday.
Panels will be about as tall as full-grown corn
Panels will be tallest at sunrise and sunset, when they will be turned toward the sun. Panel rotation will stop at 30 degrees from vertical to further limit glare in the area around the facility. When the sun rises higher than 30 degrees above the horizon in the morning, the panels will start to track the sun across the sky, rotating to flat at midday and then returning to their tallest profile as sunset approaches.
